LiteGuide SOLID EMBOSSED Series

LiteGuide : Though belongs to the clear polycarbonate sheet category, has additives that softens and disperses light evenly, while still retaining a very high visible light transmission rate.
Best suited for greenhouse applications and commercial skylights, as we know humans and other living organisms would all like to avoid sunburn. Also suitable for Signs and Billboards.

Add to quote
Category:
Description

VULCAN Solid EMBOSSED LiteGuide Polycarbonate sheet

VULCAN LiteGuide SOLID EMBOSSED sheets can be seen as an enhanced version of Valuview Solid EMBOSSED Clear sheets.  Visible light transmission rate remains the same, but the added light diffusers disperse light evenly, creating an atmosphere with soft lighting

VULCAN LiteGuide Solid EMBOSSED sheets retain all of the great qualities of polycarbonate – 250 times over glass, 10 times over FRP and Acrylic sheets in impact strength.  Light weight, ease of installation, fireproof and weathering resistant properties make it the perfect choice for civil construction and safety glazing.

Solid EMBOSSED sheets, with its irregular, grain like surface, creates an embossed effect, providing good privacy

They can also be cold bent to shape and fixed to curved structures or façades, or hot formed to dome polycarbonate skylight covering for commercial and industrial applications.

PRODUCT OVERVIEW

PRODUCT OVERVIEW

LiteGuide Series

VULCAN LiteGuide filters incoming sunlight and interior lighting into soft and dispersed light, which eliminates burn on plants, vegetation, animals and human beings. The light softening properties comes from VULCAN’s proprietary LiteGuide resin added to the Covestro base, and with the help of Avient CESA Light UV and Light Stabilizers co-extruded on the surface, maximizes the lifespan of your VULCAN LiteGuide polycarbonate sheet.

Product Strengths

Base Material

VULCAN polycarbonate sheets use only 100% Virgin Covestro UV stabilizer included master-batch.

LiteGuide Material

Designed to break up and distribute light evenly, LiteGuide will reduce hot spots and diffuse light.

LiteGuide Technology

LiteGuide softens and disperses light evenly, which suits plants and flowers, which burns when encountering direct sunlight and is best avoided. LiteGuide sheets are also suitable for Signs and Billboards, which provides good aesthetics.

LiteGuide Transmission Rate

Excellent Light transmission – 88% VIS transmission rate with complete light dispersion.

LiteGuideHigh Impact Resistance

250 times the impact strength over glass and 10 times over FRP and Acrylic.

UV Resistant Coating

Co-extruded with the Base Material, the Avient CESA Light UV and Light Stabilizers blocks harmful UV rays from 280~400nm. With co-extruded UV protection, VULCAN Polycarbonate sheets last 10 years or more.

Clean Room Manufacturing

VULCAN Sheets are produced in ISO Class 7 (FED STD 209E equivalent Class 10,000) clean room to ensure an impeccable quality.

Production Method

Co-Extrusion ensures evenly spread, evenly thick base material and UV coating.

DETAILED PRODUCT SPECIFICATIONS

DETAILED PRODUCT SPECIFICATIONS

Material Grade

Product Grade LiteGuide Light Softening sheet with CESA-Light Co-Extruded Coating
Outlook

Difusor de resina de policarbonato LiteGuide
Raw Material 100% Virgin UV Stabilized Covestro Polycarbonate resin.
Warranty 10 year warranty: 5 for yellowing, and 10 year for usage under normal conditions.
*Please refer to the installation instructions and list of harmful chemicals. Failure to comply shall void warranty.
Light Transmission Rate 88%
UV Protection Avient CESA-Light co-extruded UV and Light Stabilizers. Double layered Co-Extruded coating process results in a longer lifespan compared with other brand products.
Properties LiteGuide provides soft and diffused lighting, reducing direct sunlight penetration, while still maintaining high light transmission rates.
Places to Used Recommended in areas requiring abundant but lambent lighting to create a relaxing atmosphere. Also recommended on billboard and signboards.



Material Properties

Material Grades LiteGuide
Color ICE
LIGHT TRANSMISSION 88%
UV UV400 Co-Extruded ●
Included in Raw Material ●
Warranty 5yrs (Yellowing) ●
10yrs (Usage) ●
1yr
Transparent
Translucent ●
Lighting Direct
Diffused ●
Shading Excellent
Average
Minumum ●
IR Control Excellent
Minimum ●
Poor
PAR Control Excellent
Average
Minimum ●



Sheet Properties

Material Typical Properties Test Method Results Remark
Tested on 1.5mm LiteGuide Sheets
Tensile Strength @yield (kgf/cm²) CNS 11335 670 Should exceed 551（kgf/cm²）

Tensile Elongation (%)

 CNS 11335 57 Should exceed 50%
Impact Strength CNS 12093 No Rupture Mean Value of 3 Specimen
Change Percentage of Yellow Index (YID) after Weathering Resistance test (1200hrs) ASTM G154

ASTM E313

 ΔYI -0.49
Visibile Light Transmittance (%) ASTM D1003 0.20
Ultraviolet Transmittance (%) ASTM D1003 1.3
Density (ρ) ASTM D792 1.20 g/cm³
Burn Characteristics CNS 12093 Burnt portion self extinguishes after burner is removed. 10 Specimen Tested. Does Not Reach 25mm Reference Mark.
Properties LiteGuide provides diffused and lambent lighting, reducing direct sunlight penetration,
while still maintaining high light transmission rates.
Places to Use Specially designed for hot areas which requires lots of shade, but still require well dispersed lighting. Recommended for warehouse, patios, rainsheds, canopies, carparks, and many more.
