FIXING ROOF SHEETING TO METAL
METAL-Tite™ – CREST FIXING FASTENERS
Carbon steel fasteners for fixing steel sheets onto steel substrates
| STEEL PENETRATION |  |
| Max 6.0mm thick (For #12 gauge) | |
| ADAPTER TO USE | |
| Magnetic Hex Socket (5/16″) | |
 | |
| PRODUCT FEATURES | |
| Hex Washer Flange Thunder-Shot Point Double Thread Scratshank | |
| WASHER | |
| Eco-BDN® Green Washer | |
 |
 |  |  |
| BN2 Series SST 500 hrs + 5 cycles | BN3 Series SST 1000 hrs + 7 cycles | BN+ Series SST 1000 hrs + 15 cycles |
| SDHCG1245C2N 12-14 x 45mm SDHCG1248C2N 12-14 x 48mm SDHCG1255C2N 12-14 x 55mm SDHCG1265C2N 12-14 x 65mm SDHCG1275C2N 12-14 x 75mm SDHCG1285C2N 12-14 x 85mm | SDHCG1245C3N 12-14 x 45mm SDHCG1248C3N 12-14 x 48mm SDHCG1255C3N 12-14 x 55mm SDHCG1265C3N 12-14 x 65mm SDHCG1275C3N 12-14 x 75mm SDHCG1285C3N 12-14 x 85mm | SDHCG1245C3+N 12-14 x 45mm SDHCG1248C3+N 12-14 x 48mm SDHCG1255C3+N 12-14 x 55mm SDHCG1265C3+N 12-14 x 65mm SDHCG1275C3+N 12-14 x 75mm SDHCG1285C3+N 12-14 x 85mm |
